Scenario: S3 Bucket Malware Scanning

Prerequisites

• Vision One Cloud Security File Scanner API-Key with the following permissions:
  • Cloud Security Operations
    • File Security
      • Run file scan via SDK
• Know your Vision One region.

PGO S3 Scanning

This scenario uses Playground Ones own S3 Bucket Scanner which is not the official solution component of Vision One. It uses the File Security Python SDK within a Lambda Function. Scan results will show up on the Vision One console.

Limitations

• Maximum file size 1GB
• The scanned files are neither tagged nor quarantined, just scanned.

Architecture

The scanner consists out of the following components:

• A Lambda function triggered by s3:ObjectCreated events. It uses the File Security Python SDK via gRPC.
• The function uses a custom layer containing the required dependencies including the SDK.
• An S3 Bucket with the permission to notify the Lambda.
• An IAM Role and Policy.

Note: Lambda will use Python 3.11

The Function Code

Below are the relevant sections of the function code:

import json
import os
import time
import urllib.parse

import amaas.grpc
import boto3

v1_region = os.getenv("V1_REGION")
v1_api_key = os.getenv("V1_API_KEY")

s3 = boto3.resource("s3")


def lambda_handler(event, context):

    print(f"event -> {str(event)}")

    handle = amaas.grpc.init_by_region(v1_region, v1_api_key, True)

    for record in event["Records"]:

        bucket = record["s3"]["bucket"]["name"]
        key = urllib.parse.unquote_plus(record["s3"]["object"]["key"], encoding="utf-8")

        pml = True
        feedback = True
        verbose = True
        digest = True

        try:
            s3object = s3.Object(bucket, key)
            # Load file into a buffer
            buffer = s3object.get().get("Body").read()

            s = time.perf_counter()

            # Scan the file
            scan_resp = amaas.grpc.scan_buffer(
                handle,
                buffer,
                key,
                tags=["pgo"],
                pml=pml,
                feedback=feedback,
                verbose=verbose,
                digest=digest,
            )

            scan_result = json.loads(scan_resp)
            elapsed = time.perf_counter() - s
            print(f"scan executed in {elapsed:0.2f} seconds.")
            print(f"scan result -> {str(scan_result)}")

        except Exception as e:
            print(e)
            print("error scan object {} from bucket {}.".format(key, bucket))

    amaas.grpc.quit(handle)

Deployment

Assuming you have set your Vision One API Key and Vision One region with the help of the config tool simply run

pgo --apply s3scanner

The following outputs are created:

Outputs:

aws_lambda_function_name = "pgo-id-bucket-scanner-2kn1vopd"
aws_lambda_layer_arn = "arn:aws:lambda:eu-central-1:634503960501:layer:pgo-id-filesecurity-layer-2kn1vopd:1"
aws_s3_bucket_name = "pgo-id-scanning-bucket-2kn1vopd"

Feel free to review the Lambda function in the AWS console.

Run Scans

Either head over to the S3 bucket via the console to upload files or use the AWS cli.

Download the eicarcom2.zip and upload it to the scanning bucket.

Warning: Do not download malicious files on computers with a running anti malware engine!

# Set your bucket name from the outputs
SCANNING_BUCKET=pgo-id-scanning-bucket-2kn1vopd

wget https://secure.eicar.org/eicarcom2.zip
aws s3 cp eicarcom2.zip s3://${SCANNING_BUCKET}/eicarcom2.zip

Check on Vision One

When heading over to your Vision One console to Cloud Security Operations --> File Security you should see scan results with potentially detected malware.

🎉 Success 🎉
